HEAT SINK
EXTRUSION PROFILES
XINXIANG maintains a growing selection of existing aluminum extrusion tooling for heat sink production.
Get Started With an Existing Heat Sink Profile.
Existing tooling
Faster Turnaround
Cost-Effective
No New Tooling Fee
Customizable
Cutting, Drilling, CNC, Surface Finishing
All profiles below are available from existing tooling, with no new die charge required. Existing profiles can be cut, machined, anodized, or further customized for your application. Enter your required dimensions to find matching profiles.
Know the profile number? Enter it here.
Enter a minimum, maximum, or both.
Height includes the base. Enter a minimum, maximum, or both.
Enter a minimum, maximum, or both.
Height includes the base. Enter a minimum, maximum, or both.
Can’t Find an Exact Match? If you can’t find a suitable profile, we can also develop a custom extrusion based on your drawing or required dimensions. With our extensive tooling and manufacturing experience, custom extrusion die costs are typically competitive.
Send us your drawing or requirements, and we’ll help you find the right solution.
Frequently Asked Questions
Are all profiles shown on this page available from existing tooling?
The profiles shown in this library are based on our existing tooling resources. Tooling condition, current production availability, exact dimensions, and project suitability are confirmed during quotation.
Does using an existing profile eliminate the extrusion die cost?
It may. If an existing tool can be used directly for your project, new die development may not be required. Final tooling requirements depend on the profile, tolerances, quantity, and production specifications.
Can I change the width or fin dimensions of an existing profile?
The basic extruded cross-section is determined by the extrusion die and normally cannot be freely changed. However, some dimensions or features may be modified through cutting or CNC machining. If significant cross-section changes are required, a new extrusion die may be more appropriate.
For a step-by-step approach to comparing width, height, base thickness, fin geometry, and machining requirements, see our guide on how to choose a heat sink extrusion profile.
Can you cut an existing profile to my required length?
Yes. Extruded profiles can be supplied cut to the required length, subject to project tolerances and manufacturing review.
Can you machine holes, threads, slots, or pockets after extrusion?
Yes. We provide secondary CNC machining including drilling, tapping, milling, slots, pockets, mounting features, and interface machining.
What surface finishes are available?
Common options include mill finish, clear anodizing, black anodizing, powder coating, and conversion coating. Other finishes can be evaluated according to your specification.
Learn more in our Heat Sink Surface Finishes guide.
What should I send when requesting a quote?
If you already know the profile number, send us the XHS number together with the required length, quantity, machining details, surface finish, tolerances, and drawing if available.
If you do not know which profile to use, send us your target dimensions or existing drawing and we can help identify a suitable starting point.
Can you develop a completely new extruded heat sink profile?
Yes. If no existing profile is suitable, we can review your drawing or thermal and mechanical requirements and evaluate a custom extrusion design.
Request A Quote
Send us the profile number you are interested in, or upload your drawing and dimensions.
We can help determine whether an existing extrusion can be used or whether a custom profile would be more suitable for your project.
You can also contact our team at sales@heat-sinks.com
